Operating conditions:
1. Liquid temperature up to 60℃
2. Ambient temperature up to 40℃
3. Total suction lift to 8m
4. Continuous duty
Motor
1. Two-Pole induction motor (n=2900r. P. M. )
2. Insulation Class: B/F
3. Protection: IP44
Material
1. Pump body: Cast Iron/Brass insert
2. Motor Support: Cast Iron
3. Impeller: Brass
4. Shaft with rotor: 45# Carbon Steel/Stainless Steel
5. Mechanical seal: Carbon/Ceramic
Application:
-Volumetric water pumps able to offer high pressures in relation to comparatively low powers and which have particularly steady operating curves.
-They are qualified in domestic fittings, to in crease the system pressure in aqueducts and for automatic water distribution by small autoclave tanks or by hydrosphere units.
-For the correct functioning of the pump, use clean water, or non-aggressive liquids only, without sand or other solid impurities.
|
NO. |
TYPE |
POWER |
MAX.FLOW |
MAX.HEAD |
INLET/OUTLET |
MAX.SUCT |
N.W |
PACKING DIMENSION |
|
|
(Kw) |
(Hp) |
(L/min) |
(m) |
(Inch) |
(m) |
(K.g) |
(mm) |
||
|
A |
KF-1 |
0.37 |
0.5 |
35 |
30 |
1"*1" |
9 |
5.5 |
260*145*175 |
|
|
|||||||||
|
|
|||||||||
